Hardcore implementation of engineering design: Precise transformation from concept to mass production
With an engineering mindset running through the entire design process, we overcome technical challenges in complex scenarios to ensure the efficient implementation of the design as a mass-produced, reliable chip product:
Complex system integration engineering capability: Possessing the strength to integrate ultra-large-scale heterogeneous systems, we can complete the collaborative design of "CPU + GPU + NPU + ISP" multi-core heterogeneous architecture. Through our self-developed InterConnect™ interconnection protocol, we achieve low-latency communication between core components, with an interconnection bandwidth of 2TB/s and latency controlled within 10ns. We successfully implemented a high-end intelligent driving chip, integrating 128 NPU computing cores, 8-core CPU, and 2-core GPU, with a chip area of only 320mm². It achieves extreme power consumption control while meeting functional requirements, with typical scenario power consumption reduced by 28% compared to similar products.
Extreme scenario engineering optimization capability: For extreme application environments such as high temperature, high voltage, and strong interference, we establish a specialized engineering optimization system. In industrial control chip design, through hierarchical power network layout and EMC (electromagnetic compatibility) simulation optimization, we achieve 8kV surge protection capability, meeting the industrial-grade IEC 61000-4-5 standard; in automotive-grade chip design, we adopt "redundant design + fault-tolerant algorithm" dual guarantees, with a fault tolerance rate of 99.999% for key signal paths, and passing ISO 26262 ASIL-D functional safety certification, enabling stable operation in a -40℃ to 150℃ wide temperature range.
Pilot production-oriented engineering adaptation capability: Deeply integrating the requirements of mass production processes, we achieve seamless connection between design and manufacturing. For 12-inch wafer mass production processes, we optimize the lithography friendliness of the chip layout, through sub-resolution auxiliary graphics (SRAF) insertion and lithography contrast optimization, expanding the lithography process window by 40%, and increasing the yield by 15 percentage points compared to the initial design; in packaging engineering design, we adopt the SiP (system-level packaging) integrated solution to solve the problem of multi-chip collaborative heat dissipation, reducing packaging parasitic parameters by 30%, and improving the overall reliability by 40%, with a stable production test pass rate of over 99%.
Engineering problem rapid breakthrough capability: Establishing a "simulation - testing - iteration" closed-loop engineering breakthrough mechanism, equipped with a professional engineering verification team and advanced laboratory equipment. For problems such as timing convergence and power consumption exceeding standards that occur after chip prototyping, we can quickly locate the bottleneck through PrimeTime timing analysis tools, and achieve optimization and iteration within 72 hours by combining physical layout adjustments; in the production stage of an AI chip, we successfully overcame the problem of high-speed interface signal integrity, by adjusting transmission line impedance matching and optimizing PCB layout, reducing the interface bit error rate from 10⁻⁶ to 10⁻¹², ensuring the quality of batch delivery.
